SKU: 199977
Noris
Wartsila
Title, Supplementary Title/Description: Temperature Sensor
Tp23/For Protection Tube
Typ/Type: Tp23-2500
Pn: B82340#001
Meter= 2.5
Part No, Drawing No.: 60 230
Part Code: 9311/A102
Order No./Item: 0041198601/000200
Engin Type/No.: 8S20H/22354
Measuring Element:
Platin-sensor: Acc Iec 60751
Range: -25 200˚C
Nominal Resistance: 100Ω@0˚C
Tolerance: Class F0,3(B)(±0,12Ω/±0,3˚C@0˚C)
Measuring Current: Max 5Ma Recommended 2,5Ma
Insulation Resistance: Greater Than 10MΩ@500V Dc
Protection Class: En 60529 Ip65(Open Cable Tails Ip00)
Weight: 120 Gm
