SKU: 122283
| Attribute | Details |
|---|---|
| Brand | ABB Oy |
| Model | ACS850-04-144A-5+D150+J400 |
| Product Type | AC Drive Module (VFD / Variable Frequency Drive) |
| Product Code | 3AUA0000022303 |
| Frame Size | E0 |
| Input Voltage (U1) | 3~ 380–500 V AC |
| Input Current (I1N) | 142 A |
| Input Frequency (F1) | 48–63 Hz |
| Output Voltage (U2) | 3~ 0–U1 V |
| Output Current (I2N) | 144 A |
| Output Frequency (F2) | 0–500 Hz |
| Power Rating | 75 kW / 100 HP |
| Protection Class | IP20 |
| Relay Output | 250 VAC / 30 VDC, Max 2A |
| Control Units | JCU-11, JINT-E02C, RINT5514, RVAR-5512 |
| Firmware | Uifi2700 / N2000 |
| Compliance | 94V-0 |
| Wire Requirement | 75°C Rated Wire Minimum |
| Additional Codes | 68834309D, 68834317G, 64698001B |
| Country of Origin | Finland |
| Weight | 38 Kg |
The ABB ACS850-04-144A-5+D150+J400 AC Drive Module is a versatile VFD that provides superior performance in controlling motors in industrial automation processes. This drive module is manufactured by ABB Oy and has an input voltage rating of 3-phase 380–500V with a rated output current of 142A.
The ABB ACS850-04-144A-5+D150+J400 AC Drive Module uses ABB’s state-of-the-art ACS850 technology to guarantee high efficiency in energy use, effective torque control, and efficient motor operation. It features a power rating of 75 kW (100 HP) and a maximum output frequency rating of 500 Hz.
Key Features:
1. High Power Industrial Drive (75kW / 100HP): Developed to cater to industrial applications where robust and energy-efficient motor drive is required.
2. Wide Operating Voltage (380-500VAC): To provide compatibility in all standard industrial power supply circuits across the world.
3. High Operating Current (142A Input / 144A Output): Enables heavy loading with continuous operation within an industrial environment.
4. ACS850 Drive Technology: Offers precise motor speed control, minimizing energy losses, and high system efficiency.
5. Wide Operating Frequencies (0-500Hz): Allows flexibility in speed control as per industrial requirements.
6. Modular Drive Architecture: Consists of control modules, namely JCU-11, JINT-E02C, and RINT models.
7. Relay Output Control Capability: Allows automatic control with switch voltage of 250VAC or 30VDC.
8. Small IP20 Housing: For convenient installation within the industrial panel or cabinet.
9. Industrial-grade Product Quality: Engineered for durability and extended product lifespan in challenging environments.
Applications:
1. Industrial Automation Systems: For the accurate regulation of motors used in automated manufacturing processes.
2. Pump and Compressor Systems: For ensuring energy efficiency in speed and pressure regulation.
3. Conveying and Handling Systems: For ensuring controlled speed and regulation of conveyor movement.
4. Air Condition and Ventilation Systems: To optimize air flow and energy efficiency in buildings.
5. Manufacturing Machinery: Applicable for use in CNC machines, processing plants, and other heavy machinery.
6. Energy Systems: Suitable for applications in auxiliary drive systems.
Explore our wide range of industrial drive systems designed for efficient motor control and automation by visiting our dedicated Drives category page for reliable and high-performance solutions.
