SKU: 60568
| Attribute | Value |
|---|---|
| Manufacturer | Fuji Electric Co., Ltd. |
| Product Type | Auxiliary Relay / Latch Unit |
| Model | SH-5/V |
| Sub Model | SH05AV-M31 |
| Voltage Rating | 200-220V 50Hz / 220-240V 60Hz |
| Contact Configuration | 3A1B (3NO 1NC) |
| Power | 3425W |
| Part | Latch Unit / Relay |
| Series | SZ-V200 |
| Reference Code 1 | F07865045B |
| Type | SH-5 |
| Standards | A600 Q300, JISC4531, IEC337-1, VDE0660, BS 4794 |
| Contact Type (Alternate) | 4A1B (4NO 1NC) |
| Current Rating | Ith = 10A |
| Reference Code 2 | F07766024F |
| Reference Code 3 | F07865455B |
| Equipment | Group Starter Panels |
| Equipment Part No. | 873.005-024 |
| Country of Origin | Japan |
| Weight | 500 Gm |
The Fuji Electric SH-5/V Latch Unit, used with SH-5, is an extra relay system designed to work in industrial control and automation projects. Fuji Electric Co., Ltd. created the latch unit which is a common choice in starter panels, motor control centers and electromechanical interlocking systems. Reliability is its main feature, as the SH-5/V remember their states after losing power, so they suit areas where information needs to be retained even when powered down. This unit operates at 200–220V (50Hz) and 220–240V (60Hz) and is compliant with JISC4531, IEC337-1, VDE0660 and BS 4794, so it is safe and compatible in a range of industrial environments. Being designed to be small, having multiple contacts and being durable, it is well suited to places with a lot of wear and constant service.
Key Features:
1. Locking and Unlocking Function: Offers a mechanical solution that holds the contact position after it has been acted on, even when power is lost—helpful for keeping information in control circuits.
2. Wide Voltage Range: This motor fits 200–220V (50Hz) or 220–240V (60Hz) power systems, allowing it to be used around the world.
3. Flexible Contact Configuration: Available in 3A1B (3NO + 1NC) and 4A1B (4NO + 1NC) variants so users have more options for how to use their circuits.
4. Compact and Panel-Mountable: Especially prepared for saving space in starter panels and control cabinets and simple to connect with existing systems.
5. Durable and High-Performance: Its rated thermal current (Ith) is no more than 10A, making it ideal for uses that need frequent and durable heavy-duty switching.
6. Standard-Compliant: Follows standards such as A600 Q300, IEC337-1 and VDE0660 which provide the proper safety, efficiency and regulatory fulfillment needed.
7. Industrial-Grade Build: Especially developed for tough conditions, they last for a long time and need little upkeep.
Applications:
1. Motor Control Centers (MCCs): To start the motors of fans, compressors, conveyors and pumps in industrial plants, start signal commands are used in the main control panel (MCC).
2. Starter and Contactor Panels: Is an important part of group starter panels, allowing you to control several motors or devices from one system.
3. Oil & Gas and Chemical Facilities: Holds shutdown and safety functions in place after the loss of main power.
4. Factory Automation: In manufacturing automation equipment, interlocks, sequential logic control and signal memory systems use this.
5. Marine and Offshore Systems: These are used on ships in electrical control panels to maintain control information in situations of high shaking and moisture.
6. Power Distribution Panels: Using latching devices to keep the commands safe for the power management and distribution systems in switchgear and relay panels.
Discover durable and high-performance Siemens Relays at Aeliya Marine, ideal for industrial automation and electrical control systems.
